The automatic bagging machine is mainly suitable for self-adhesive bag packaging of regular sheet products and printed materials,such as books, cards, red envelopes, instructions, document bags, folders, paper, desk calendars, flat covers, mobile phone cases,etc.
The automatic bagging machine is mainly suitable for self-adhesive bag packaging of regular sheet products and printed materials,such as books, cards, red envelopes, instructions, document bags, folders, paper, desk calendars, flat covers, mobile phone cases,etc.
Specification
Item |
Details |
Packaging Materials |
OPP, CPP, PP, PE materials; it is required to be used in rolls, and the diameter of the inner shaft is 75mm; the surface of the film should be flat, the edges should not be wavy, and the color code and the background color of the packaging film should be clearly contrasted. (Material should not be too brittle) |
Bag Width Size |
100mm-280mm |
Bag Length |
100-300mm |
Packaging Product Height |
15mm(hard card type) according to the sample |
Bagging Speed |
30-50bag/min (The bag length and bag width are determined by the product height) |
Film Thickness |
0.03-0.05mm |
Roll Film Outer Diameter |
max≤450mm |
Roll Film |
It needs to be folded in half, leaving the tongue mouth (can be flat,) with automatic deviation correction |
Tongue Length |
≤30 mm According to the product height |
Power |
380V、50HZ13KW |
Power Quantities |
7pcs*servo motro 2pcs*frequency transformer |
Air |
0.6MP≤pressure≤0.8MP mm |
Air Brand |
|
Machine Size |
H 800mm L5000mm×W4000mm |
Operating Height |
800mm |
Friction Feeder |
Optional |
Remark |
Machine picture for reference |
